The Tesla Model 3 BBK is an electric four-door fastback sedan developed by Tesla. The Model 3 BBK Standard Range Plus version delivers an EPA-rated all-electric range of 263 miles (423 km) and the Long Range versions deliver 353
miles (568 km). According to Tesla, the Model 3 BBK carries full self-driving hardware, with periodic software updates adding functionality.
Limited production of the Model 3 BBK began in mid-2017, with the
first production vehicle rolling off the assembly line on July 7,
2017.The official launch and delivery of the first 30 cars took
place on July 28.
As of March 2020, the Tesla Model 3 BBK is the world's best-selling
electric car in history, with more than 500,000 units delivered.The
Model 3 was the world's top selling plug-in electric car in 2018 and 2019,and also the best-selling plug-in car in the
United States. The Model 3 BBK was also the top selling plug-in car
in Europe in 2019
What's in the Box
Passenger Side Front TEI Racing Six-Piston Caliper
Driver Side Front TEI Racing Six-Piston Caliper
2-piece TEI Racing Front Rotors
Braided Stainless Steel Brake Lines
Brake Pads (one set, for both calipers)
Mounting Brackets
Installation Hardware
Features
TEI Racing Bolt-On Front Brake Kit
6 Piston Aluminum Calipers
2-piece (378mm/405mm) Type 1 Slotted /Drilled Brake Rotors
Braided Stainless Steel Lines
Compatible with Factory Master Cylinder, ABS and Traction Control
System
Package size:42*42*42cm
Piston material: Aluminum Alloy
Brake Pads
Material: Ceramic Graphite
Heat Resistant:0-500C
Friction Coefficient:0.49
Rotor (Disc+Center Hub)
craft: Forged
Plane Bounce:<0.03mm
Material:
1,Disc:High Carbon Iron
2,Center Hub: Aerial 6061 Aluminum Alloy
ROTOR SPECS:
2-piece floating rotors with 6061-T6 aerospace grade alloy hat.
Fully balanced from the factory
Rotor ring in FC30 cast iron with anti corrosion coating.
Drilled / slotted / drilled and slotted rotor ring available at no
extra cost.
(We advise drilled for street and slotted only for track and race
applications)
Curved vanes ventilation for optimal cooling.
Full-floating rotors use floating hardware with anti-rattle system
(removable and rebuildable).
It provides a lower tendency to warp, less drag and wear as the
rotor ring centers itself with the pads.
Available for 330mm rotors and bigger only.
The semi-floating rotor uses standard bolts instead and the rotor
is fixed on the hat.
Custom rotor hat anodized color
Brackets/Adapters
Material: Aerial 6061 Aliminum Alloy
Craft: CNC
Brake Hose/Brake line
Material: Inside teflon, Braided Stainless steel mid layer
,Protective outer PVC weather proof shell
Our brake kit is supplied with a Goodridge Style Brake line kit
with stainless lines; consisting of a PTFE inner and stainless
steel braided outer to eliminate the spongy feel of original rubber
hoses, provide superior resistance to corrosion, and offer
consistent braking performance.
WARRANTY:
10 years on calipers casting, caliper parts, and seals.
2 years on mounting hardware and brackets.
Lifetime Warranty on brake lines. DOT approved
10,000km / 3 months on rotors.
The number of pots of the calipers will also play a role in term of
pressure applied on the pads to make the contact as good as
possible on the rotors. In order to fit the caliper on your
original chassis, TEI Racing provides caliper brackets to position
the calipers with your new braking system, making the perfect set
up for your car brakes system.
Go fast and stop faster. TEI Racing Big Brake Kits provide you with
serious braking power when you need it most. TEI Racing brake kits
are offered for both the front and rear brakes with rotor sizes
ranging from 285mm-405mm drilled or slotted or drilled and slotted,
2-6 piston Forged Monoblock aluminum caliper options, and custom
colors. Stainless steel brake lines, brake pads, and all hardware
are included for a direct bolt-on installation where no
modifications are required.
TEI Racing Monoblock calipers are precision machined from aircraft
quality billet aluminum and feature heavy duty aluminum pistons
mated to temperature resistant seals. These high performance
calipers are able to utilize a lightweight construction while
providing dramatically increased braking performance. The rotors
included in TEI Racing big brake kits features a two-piece design
with drilled or slotted surfaces which help minimize fade and
dissipate heat under the most extreme braking.
| TEI Racing Rotor Size | Minimum Inch Wheel Size |
| 285*24mm | 15inch wheels |
| 300*24mm | 16inch wheels or above |
| 300*28mm | 17inch wheels or above |
| 330*28mm | 17inch wheels or above |
| 345*28mm | 18inch wheels or above |
| 355*32mm | 18inch wheels or above |
| 378*32mm | 19inch wheels or above |
| 405*34mm | 20inch wheels or above |
Installation Info
Installation Time
(approx) 4 Hours
Difficulty Level:
Mechanical expertise or professional installation required.
