BBK For Subaru WRX/STi Big Brake Kit Front P60S Forged 6 Piston
Calipers 18inch Wheel
The Subaru WRX is an all-wheel drive sport compact car manufactured by Subaru, originally based on the Impreza created for the World Rally Championship in 1992.Subaru claimed the name WRX stands for "World Rally
eXperimental". Since 2014, the WRX lineup has been split from the
Impreza, with a different body style also being used for WRX
models. After this point, there has been an absence of a hatchback/wagon body style
What's in the Box
Passenger Side Front TEI Racing Six-Piston Caliper
Driver Side Front TEI Racing Six-Piston Caliper
2-piece TEI Racing Front Rotors
Braided Stainless Steel Brake Lines
Brake Pads (one set, for both calipers)
Mounting Brackets
Installation Hardware
| Big Brake kit Model P60S |
| Brand | TEI | Craft | Two-piece Forged Body | Caliper Length | 289mm |
| Model | P60S | Caliper Material | Aerial 6082 Aluminum Alloy | Caliper Width | 165mm |
| Pistons | 6 POTS | Piston Material | Aluminum Alloy | Caliper Height | 88mm |
| Logo | Carved | Piston Diameter | 38.1mm 31.8mm 27mm | Caliper Weight | 3.2kg/pcs |
Package size:42*42*42cm
Piston material: Aluminum Alloy
Brake Pads
Material: Ceramic Graphite
Heat Resistant:0-500C
Friction Coefficient:0.49
Rotor (Disc+Center Hub)
craft: Forged
Plane Bounce:<0.03mm
Material:
1,Disc:High Carbon Iron
2,Center Hub: Aerial 6061 Aluminum Alloy
ROTOR SPECS:
2-piece floating rotors with 6061-T6 aerospace grade alloy hat.
Fully balanced from the factory
Rotor ring in FC30 cast iron with anti corrosion coating.
Drilled / slotted / drilled and slotted rotor ring available at no
extra cost.
(We advise drilled for street and slotted only for track and race
applications)
Curved vanes ventilation for optimal cooling.
Full-floating rotors use floating hardware with anti-rattle system
(removable and rebuildable).
It provides a lower tendency to warp, less drag and wear as the
rotor ring centers itself with the pads.
Available for 330mm rotors and bigger only.
The semi-floating rotor uses standard bolts instead and the rotor
is fixed on the hat.
Custom rotor hat anodized color
Brackets/Adapters
Material: Aerial 6061 Aliminum Alloy
Craft: CNC
Brake Hose/Brake line
Material: Inside teflon, Braided Stainless steel mid layer
,Protective outer PVC weather proof shell
Our brake kit is supplied with a Goodridge Style Brake line kit
with stainless lines; consisting of a PTFE inner and stainless
steel braided outer to eliminate the spongy feel of original rubber
hoses, provide superior resistance to corrosion, and offer
consistent braking performance.
WARRANTY:
10 years on calipers casting, caliper parts, and seals.
2 years on mounting hardware and brackets.
Lifetime Warranty on brake lines. DOT approved
10,000km / 3 months on rotors.
The number of pots of the calipers will also play a role in term of
pressure applied on the pads to make the contact as good as
possible on the rotors. In order to fit the caliper on your
original chassis, TEI Racing provides caliper brackets to position
the calipers with your new braking system, making the perfect set
up for your car brakes system.
Go fast and stop faster. TEI Racing Big Brake Kits provide you with
serious braking power when you need it most. TEI Racing brake kits
are offered for both the front and rear brakes with rotor sizes
ranging from 285mm-405mm drilled or slotted or drilled and slotted,
2-6 piston Forged Monoblock aluminum caliper options, and custom
colors. Stainless steel brake lines, brake pads, and all hardware
are included for a direct bolt-on installation where no
modifications are required.
TEI Racing Monoblock calipers are precision machined from aircraft
quality billet aluminum and feature heavy duty aluminum pistons
mated to temperature resistant seals. These high performance
calipers are able to utilize a lightweight construction while
providing dramatically increased braking performance. The rotors
included in TEI Racing big brake kits features a two-piece design
with drilled or slotted surfaces which help minimize fade and
dissipate heat under the most extreme braking.
| TEI Racing Rotor Size | Minimum Inch Wheel Size |
| 285*24mm | 15inch wheels |
| 300*24mm | 16inch wheels or above |
| 300*28mm | 17inch wheels or above |
| 330*28mm | 17inch wheels or above |
| 345*28mm | 18inch wheels or above |
| 355*32mm | 18inch wheels or above |
| 378*32mm | 19inch wheels or above |
| 405*34mm | 20inch wheels or above |
Installation Info
Installation Time
(approx) 4 Hours
Difficulty Level:
Mechanical expertise or professional installation required.
