    W204 Mercedes Big Brake Kit 17 Inch Car Rim Front 4 Piston Brake Kit Auto Brake System

    Ask Lasest Price
    Brand Name : TEI-RACING
    Model Number : P40NS
    Certification : China National Inspection Agency
    Payment Terms : L/C, T/T, Western Union, MoneyGram and so on
    Supply Ability : 10000 sets per month
    Delivery Time : 10-15 DAYS
    • Product Details
    • Company Profile

    W204 Mercedes Big Brake Kit 17 Inch Car Rim Front 4 Piston Brake Kit Auto Brake System

    High Performance BBK For Mercedes-Benz C Class W204 17 Inch Car Rim Front 4 piston brake kit auto brake system


    Mercedes-Benz W204 2007-2014 year

    It can be installed our front and rear brake kit

    Minimum Rear Rotor Size is 345 mm

    Normal handbrake

    The original wheels do not need to add Spacers.


    (W204 is the code of Mercedes -Benz C -Class. Its models are: Mercedes -Benz C180, C200, C260, C300.The 2021 C200 is an example. The body size is: 4784mm long, 1810mm wide, 1457mm height, 2920mm in wheelbase, 66L of the fuel tank, and 4 -door body structure. The Mercedes -Benz C -Class 2021 C200 is equipped with a 1.5T turbocharged engine with a maximum power of 115kW and a maximum torque of 250Nm. Extreme independent suspension.)


    Orginal Brake Rotor Information


    Front Original Rotor Information
    Brake Rotor modelEK28318 or 28317
    Rotor Diameter295 mm
    Rotor Hat Diameter112 mm
    Central Hole Diameter67 mm
    Disc Thickness28 mm
    Minimum Disc Thickness25.4 m
    Total Height58.5 mm
    Number of Positioning Holes5
    Disc typeVentilation

    Rear Original Rotor Information
    Brake Rotor model12251(12186)
    Rotor Diameter300 mm(278 mm)
    Rotor Hat Diameter112 mm
    Central Hole Diameter67 mm
    Disc Thickness10 mm(9 mm)
    Minimum Disc Thickness8.3
    Total Height58 mm
    Number of Positioning Holes5
    Disc typeSolid

    Installation Case


    Installation Case Brake Kit Information
    Car ModelMB W204
    FrontRear
    TEI Caliper Model P40NS/
    Caliper ColorBLACK/
    Rotor Size330X28 MM/
    Rotor StyleSLOTTED/
    Bolt TypeFIXED/
    Brake Pad TypeSPPA/

    Noted:1.You can click the caliper model to check the products information.For example,You can click P40NS to check the P40NS brake information.

    2.SPPA=Normal Ceramics Brake Pad,SPPL=Normal Metal Brake Pad

    SSS,XSS,MSS=Racing Metal Brake Pad
